NEW BIRMINGHAM H-6014

Florida, United States
3,961Listings|11Followers
Overview
Power Squaring Shears (Gauge)

Discover precision with the BIRMINGHAM H-6014 Deluxe Shear. New 5 ft blade, 18 ga. shearing capacity, and 30 strokes per minute. Equipped with 5 hp motor, 24" front and back gauges for enhanced control. Ideal for mild and stainless steel projects.

Specs
Max Sheet Size (ft)
5'
1,524 mm
Max Sheet Size (in.)
61"
154.9 cm
Length of Blade
5'
1.5 m
Length of Blade
61"
1,549.4 mm
Shearing Capacity - Mild Steel
14 gauge
14 gauge
Shearing Capacity - Stainless Steel
18 gauge
18 gauge
Strokes Per Minute (S.P.M.)
30
30
Rake Angle
1° 40'
1° 40'
Front Gauge
24"
609.6 mm
Back Gauge
24"
609.6 mm
Motor Power
5 hp
3.7 kW
Dimensions
84" x 36" x 55"
84" x 36" x 55"
Weight
3,200 lbs.
3,200 lbs.

Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts

Machine Photo May Include Optional Equipment
Product image is only a representation, actual product appearance may differ slightly
