NEW TENNSMITH HBU72-16
USD $6,125.00
Overview
Description
TENNSMITH HBU72-16 Box and Pan Hand Brake has a bending length of 72 inches (6 feet) and 16 gauge mild steel capacity.Each hand brake is ideal for both box and pan and straight bending in hot and cold rolled plate, stainless steel, aluminum and heavy plastic.Ample clamping and nose bar adjustments allow for the bend radius necessary for your application. Welded steel plate construction and heavy truss rods and braces provide strength and rigidity.
Specifications
| Capacity (ga) Mild Steel | 16 gauge | 16 gauge |
|---|---|---|
| Capacity (ga) Stainless Steel | 20 gauge | 20 gauge |
| Bending Length (inches) | 72" | 1,828.8 mm |
| Max Box Depth | 4" | 101.6 mm |
| Beam Adjustment, Front and Back | 1" | 25.4 mm |
| Finger Widths | 2, 3 and 4 in. | 2, 3 and 4 in. |
| Minimum Flange in Capacity Material | 1" | 25.4 mm |
| Maximum Lift of Beam | 1.5" | 38.1 mm |
| Minimum Reverse Bend | 0.25" | 6.35 mm |
| Machining Length | 96" | 2,438.4 mm |
| Machine Width | 36" | 914.4 mm |
| Machine Height | 53" | 1,346.2 mm |
| Shipping Weight | 1,700 lb | 771.1 kg |
| Dimensions | 96 x 36 x 53 in. (LxWxH) Counterweights in Place | 96 x 36 x 53 in. (LxWxH) Counterweights in Place |
| Weight | 1700 lbs. | 1700 lbs. |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 3 YEAR – Limited
Equipped With
Optional Items:
Radius Fingers for HBU72-16, per inch ...... $36.00
