TENNSMITH HB73-16 Heavy Duty Hand Brake has a bending length of 73 inches (6 ft) and mild steel capacity of 16 gauge. Designed and built for long service and accurate bending. Welded steel plate construction and heavy truss rods and braces provide strength and durability. Equipped with thrust bearings, the upper leaf adjustment screws permit quick, accurate alignment for different material thickness or radii.
| Capacity (ga) Mild Steel | 16 gauge | 16 gauge |
| Bending Length | 73" | 1,854.2 mm |
| Beam Adjustment | 0.5" | 12.7 mm |
| Min Reverse Bend | 0.25" | 6.35 mm |
| Maximum Lift of Beam | 1.875 | 1.875 |
| Minimum Flange in Capacity Material | 1" | 25.4 mm |
| Machines Dimensions L/W/H | 114 x 48 x 59-1/2b in. Counterweights in Place | 114 x 48 x 59-1/2b in. Counterweights in Place |
| Shipping Weight | 1,200 lb | 544.3 kg |
| Dimensions | 114 x 48 x 59-1/2b in. Counterweights in Place | 114 x 48 x 59-1/2b in. Counterweights in Place |
| Weight | 1200 lbs. | 1200 lbs. |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 3 YEAR – Limited
