New | in-Stock

NEW BIRMINGHAM H-12014

Florida, United States
3,880Listings|10Followers
Overview
Power Squaring Shears (Gauge)

Discover precision with the new BIRMINGHAM H-12014 Deluxe Hydraulic Shear. Cuts 10' mild steel at 14 gauge and stainless at 18 gauge, powered by a 5 hp motor with 20 strokes/minute. Ideal for demanding projects with consistent performance.

Specs
Max Sheet Size (ft)
10'
3,048 mm
Max Sheet Size (in.)
122"
309.9 cm
Length of Blade
10'
3 m
Length of Blade
122"
3,098.8 mm
Shearing Capacity - Mild Steel
14 gauge
14 gauge
Shearing Capacity - Stainless Steel
18 gauge
18 gauge
Strokes Per Minute (S.P.M.)
20
20
Rake Angle
1°30'
1°30'
Front Gauge
24"
609.6 mm
Back Gauge
24"
609.6 mm
Motor Power
5 hp
3.7 kW
Dimensions
152" x 36" x 55"
152" x 36" x 55"
Weight
5,200 lbs.
5,200 lbs.

Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts

Machine Photo May Include Optional Equipment
Product image is only a representation, actual product appearance may differ slightly
