The JET ECB-1422V Dual Column Variable Speed Semi-Automatic Bandsaw has a two column design for more precise and productive cutting. Blade tension gauge helps to ensure the blade is in the correct cutting position. Swing away control box allows Operator to use in any position. Semi-auto on saw bow lifting and hydraulic vise.
| Round at 90° | 14.125" | 358.77 mm |
| Square at 90° | 14-1/8 x 14-1/8 in. | 14-1/8 x 14-1/8 in. |
| Rectangle at 90° | 14-1/8 x 22 in. | 14-1/8 x 22 in. |
| Blade Size | 1.33 x 0.043 x 192-1/8 in. | 1.33 x 0.043 x 192-1/8 in. |
| Blade Wheel Diameter | 18.5" | 469.9 mm |
| Blade Speed | 75-250 sfpm | 75-250 sfpm |
| Blade Motor | 5 HP | 5 HP |
| Power | 230/460v, 3-Phase | 230/460v, 3-Phase |
| Prewired | 230v | 230v |
| Oil Pump Motor | 1 HP, 230/460v, 3-Phase | 1 HP, 230/460v, 3-Phase |
| Coolant Motor | 1/6 HP, 230/460v | 1/6 HP, 230/460v |
| Bed/Table Height | 29" | 736.6 mm |
| Throat Depth | 14 x 17 in. | 14 x 17 in. |
| Dimensions | 93-1/2 x 25-29/32 x 72-23/32 in. | 93-1/2 x 25-29/32 x 72-23/32 in. |
| Weight | 2,266 lbs. | 2,266 lbs. |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 3 YEAR – Parts & Labor
Optional Items - Call for price:
* JT9-891161: Bundling Kit for ECB-1422V
* JT9-891162: Infeed Roller Table for ECB-1422V
* JT9-891163: Outfeed Roller Table for ECB-1422V
* JT9-891164: Bi-Metal Blade 1.33" x 0.043" x 192-1/8 4/6T for ECB-1422V
* JT9-891165: Bi-Metal Blade 1.33" x 0.043" x 192-1/8 4/6T for ECB-1422V
