The BAILEIGH R-CNC45 double-pinch tube bender ensures accuracy and minimizes flex with an electro-welded steel plate framework. Runs on 220-volt 3-phase power. Bends up to 2.5" round tube and 2" schedule 40 pipe.
| Shaft Diameter | 1.77" | 44.958 mm |
| Angle Roll Type | CNC | CNC |
| Power | 220V - 3-Phase | 220V - 3-Phase |
| Driven Rolls | 3 | 3 |
| Pinch | Single with Interchangeable Bottom Rolls | Single with Interchangeable Bottom Rolls |
| Pipe Capacity | Size: 2" (sch. 40) / Min. Dia.: 80" | Size: 2" (sch. 40) / Min. Dia.: 80" |
| Round Tube Capacity | Size: 2.5" (.100") / Min. Dia.: 60" | Size: 2.5" (.100") / Min. Dia.: 60" |
| Square Tube Capacity | Size: 2.00" (.110") | Size: 2.00" (.110") |
| Angle Iron Capacity | Size: 2" (.196") / Min. Dia.: 24" | Size: 2" (.196") / Min. Dia.: 24" |
| Distance Between Shaft Centers | Adj. (lower rolls) | Adj. (lower rolls) |
| Upper Roll Dia. | 6.693" | 170 mm |
| Lower Roll Dia. | 6.693" | 170 mm |
| Style | Double Pinch | Double Pinch |
| Digital Readout | Yes | Yes |
| Control | CNC | CNC |
| Weight | 1,728 lbs. | 1,728 lbs. |
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
