NEW SKF 3306 A/C3

Bore Size (Metric): 30 mm
Bore Size (Imperial): 1.18 in
Outside Diameter (Metric): 72 mm
Outside Diameter (Imperial): 2.84 in
Snap Ring Included: Yes
Bearing Type: Ball
Internal Clearance: C3
Overall Width: 30.2 mm
Contact Angle: 30 deg.
Contact Type: Normal Contact (two-point contact)
Number of Rows: 2
Ring Type: One-piece inner and outer rings
Cage: Sheet metal
Arrangement of Contact Angle: Back-to-back (O)
Bearing Material: Bearing Steel
Basic Dynamic Load Rating: 42.5 kN
Basic Static Load Rating: 30 kN
Reference Speed: 10,000 r/min
Limiting Speed: 9,000 r/min
