Bore Size (Metric): 110 mm
Bore Size (Imperial): 4.330 in
Outside Diameter (Metric): 230 mm
Outside Diameter (Imperial): 9.055 in
Snap Ring Included: No
Bearing Type: Thrust
Material: Bearing Steel
Bore Type: Cylindrical
Series: 294
No. of Rows: Single
Width: 73 mm
Dynamic Load Rating: 1180 kN
Static Load Rating: 3000 kN
Fatigue Load Limit: 325 kN
Reference Speed: 1600 r/min
Limiting Speed: 2800 r/min
