| Swing | 22" | 558.8 mm |
| Centers | 60" | 1,524 mm |
| Spindle Bore | 4.125" | 104.77 mm |
| Power | 15 hp | 11.2 kW |
| RPM | 0 RPM | 0 RPM |
| Swing Over Cross Slide | 14.125" | 358.77 mm |
| Dimensions | 120” x 51” x 52 | 120” x 51” x 52 |
| Weight | 5850 | 5850 |
• 15-HP Spindle Motor
• Spindle Speeds from 15 – 1200 RPM
• 12-Spindle Speed Gear-Ranges for High-Torque
• D1-11 Camlock Spindle
• 4-1/8” Spindle Bore
• Longitudinal Rapid Traverse Positioning
• Efficient 2-Speed Quill Advance
• 29-3/8” Swing in 6.5” Wide Gap
• One Piece Casting Base
Steady Rest with Roller Bearings (Capacity 4” – 10”)
Follow Rest
12” Back Plate
Full Length Back Splash Guard
Chuck Guard with Safety Interlock Switch
Foot brake
Machine Leveling Pads
Halogen Work Light (55 Watts)
