New. More options and pricing in documents link above.
| Swing | 44" | 1,117.6 mm |
| Centers | 60" | 1,524 mm |
| Spindle Bore | 6" | 152.4 mm |
| Power | 40 hp | 29.8 kW |
| RPM | 0 RPM | 0 RPM |
| Swing Over Cross Slide | 27.95" | 709.93 mm |
| Dimensions | 164” x 85” x 63”, | 164” x 85” x 63”, |
| Weight | 19500 | 19500 |
40-Horsepower Spindle Motor / 6” bore Standard
Cross & Longitudinal Rapid Feed Motor
15.74” Steady Rest w/ Roller Bearings (60-400mm range)
Quill Taper Reduction Sleeve & Dead Center
LED Work Light (55 Watts)
Full-length Back Splashguard
Safety Chuck Guard with Interlock
4-way tool post 40x40mm & wrench
