USED CONCOA 4922301-24-000

Gauge Type: Pressure
Filling: Dry
Pressure Rating: 4000 PSI
Thread Size: 1/4" FNPT
Series: 492
Outlet Pressure: 0-1500 psig (0-100 bar)
Outlet Gauge: 0-4000 psig/ 0-275 bar
Inlet Maximum: 3000 psi (210 bar)
Inlet Gauge: 0-4000 psig/ 0-275 bar
Outlet Assemblies: 1/4" FNPT
Assembly Gauges: Standard assembly (BAR/PSIG gauges)
Body, Bonnet Material: Chrome-plated brass barstock
Seats: PCTFE 3000 psig (210 bar) and 4500 psig (310 bar)inlet; or PEEK 6000 psig (415 bar) inlet option
Gauges: 2-1/2" (63 mm) diameter stainless steel
Filter: 10-micron sintered bronze
Temperature Range: -40 to 140 deg.F (-40 to 60 deg. C)
Piston: Brass barstock
Cv: 0.1
Helium Leak Integrity: 1 x 10-8 scc/sec
Internal Seals: FKM (encapsulated)
Ports: 1/4 in. FNPT
