600 volts Motor Control Center Unit Bulletin 2100

Max. Voltage: 600
Voltage: 600
Phase: 3-phase
Enclosure: Type 1
Bus Rating
Horizontal Power: 1200 Amp
Vertical Power: 300 Amp
Left Side Includes:
(2) Motor controller sections (1 section missing overload relay unit)
(1) 18 circuit breaker panelboard, max. sum breaker ratings per stab 200 amps
(1) Fuse disconnect, 100A 250V fuses
(1) 30 kVA transformer, primary 600V, secondary 208Y/120V
Right Side Includes:
(1) Motor controller section
(1) 42 circuit breaker panelboard, 225A 600V rating
(1) Fuse disconnect, 100A 250V fuses
(1) 30 kVA transformer, primary 600V, secondary 208Y/120V
