USED ALLEN-BRADLEY 1769-IF4
Overview
Specifications
Product Line: CompactLogix
Module Type: 4 Channel Analog Input Module
Product Type: Analog Input Module
Input Type: Analog Input
Compatible Controllers: MicroLogix 1500; 1769 CompactLogix
No. of Inputs: 4 Differential and Single Ended Inputs
Communication Cable: 4 Point
Power Supply Distance rating: 8
Input current range: 0-21 mA
Current signal normal ranges: 0-20mA; 4-20 mA
Series: A and B
Converter Type: Delta Sigma
Current signal full range: 0-21 mA; 3.2 - 21 mA.
Backplane Current: 1.4 Amps at 24 Volts
Input voltage range: 0-10.5VDC
Power Consumption: 33.6 Watts
Voltage signal normal ranges: +-10V DC, 0 ... 10V DC, 0 ... 5V DC, 1 ... 5V DC
External Power Switch: 24 VDC
Voltage signal full range: +-10.5V DC, -0.5 ... 10.5V DC, -0.5 ... 5.25V DC, 0.5 ... 5.25V DC
Power Dissipation: 7.5 Watts
Resolution: 14 bits (unipolar) 14 bits plus sign (bipolar)
Rated working voltage: 30VAC; 30VDC
