USED ALLEN-BRADLEY 100-C12Z*01

Rated Insulation Voltage (Uimp): 8 kV
Rated Operational Current (AC-1): 32 A at 690 V
Rated Operational Current (AC-3):
230V: 4 kW
240V: 4 kW
400V: 5.5 kW
415V: 5.5 kW
500V: 5.5 kW
690V: 5.5 kW
UL/CSA Ratings:
Max Voltage: 600V AC
Max Current: 25 A enclosed
Horsepower Ratings:
115V 1-phase: 0.5 HP
230V 1-phase: 2 HP
200V 3-phase: 3 HP
230V 3-phase: 3 HP
460V 3-phase: 7.5 HP
575V 3-phase: 10 HP
Auxiliary Contact Ratings: A600 P600
Short Circuit Rating: 5 kA at 600V
Standards Compliance: EN 60947, IEC 60947
Country of Manufacture: Switzerland
Auxiliary Contact Block (100-F)
Rated Operational Current (AC-12): 10 A at 690 V
Rated Operational Current (AC-15):
230V: 5.5 A
240V: 5 A
400V: 3 A
415V: 3 A
500V: 1.5 A
690V: 1 A
Max Voltage: 600V AC
Max Current: 10 A
Auxiliary Contact Ratings: A600 Q600
Standards Compliance: IEC/EN 60947-5-1
Compatible With: 100-C contactors and 700-C control relays
