Conduit Type: Cable Gland/Fitting
Expanded Inner Diameter: 0.125 in
Expanded Inner Diameter (metric): 3.18 mm
Flame Retardant: Yes
Flammability Rating: UL 224 All Tubing Flame Test
Inner Diameter After Shrink (Imperial): 0.062 in
Inner Diameter After Shrink (Metric): 1.57 mm
Inner Diameter Before Shrink (Imperial): 0.125 in
Inner Diameter Before Shrink (Metric): 3.18 mm
Material: Flexible Polyolefin
Maximum Operating Temperature (Celsius): 135 °C
Maximum Operating Temperature (Fahrenheit): 275 °F
Mil Spec: AMS-DTL-23053/5, Class 1
Minimum Expanded Tubing I. D.: 1 in
Minimum Shrink Temperature (Celsius): 100 °C
Non-Corrosive: Yes
Operating Temperature (Celsius): -55 to 135 Degrees Celsius
Operating Temperature Range (Celsius): -55 °C to +135 °C
Operating Temperature Range (Fahrenheit): -67 °F to 275 °F
Recovered Inner Diameter: 0.062 in
Recovered Inner Diameter (metric): 1.5748 mm
Shrink Ratio: 2:1
