NEW 2024 MIGHTY VIPER JHU-35 CNC
Overview
Description
2025 MIGHTY VIPER CNC Universal Cylindrical Grinder Model JHU-3510, Swing 13.8", Length 39.4
JHU • Universal grinding machine-The wheel headstock provides 120° of swivel angle. And the worktable swivels 5°~ 11° CCW and 3°~6° CW tailstock sleeve movement is hydraulically operated for convenient workpiece loading and unloading.
Specifications
| Swing | 13.8" | 350.52 mm |
|---|---|---|
| Centers | 39.4" | 1,000.8 mm |
| Grinding Wheel Dia. | 1,626" | 41,300 mm |
| Wheel Power | 5 hp | 3.7 kW |
| Wheel Speed | 1,600 RPM | 1,600 RPM |
| Plunge | Yes | Yes |
| Gauging | Yes | Yes |
| Dresser | Yes | Yes |
| Control | CNC (FANUC 0i TF) | CNC (FANUC 0i TF) |
| Dimensions | 128" x 82.3" 69.3" | 128" x 82.3" 69.3" |
| Weight | 1,914 lbs | 1,914 lbs |
Workpiece Swing Max. 13.8"
Grinding Length Max. 39.4"
Grinding Diameter Max. 13"
Workpiece Weight Max. (lb) 286 lbs
Grinding Wheel Motor (hp) 5 HP
Workhead Speed Range 1-500 (Variable)
Swivel Angle 120 degrees (CCW 90 degrees; CW 30 degrees)
Workhead Center MT 4
Spindle Rotation Setting Normal and Reverse
Work Table
Horizontal travel speed (mm/min) 50-3,000
Handwheel/revolution(mm) 20
Swivel Angle CCW/CW 9 degrees/ 5 degrees
Minimum travel (mm) 8
Wheel Head
Grinding Wheel Size (D x W x B) 405 x (25-50) x 152.4
Max. Peripheral 32m/sec
Grinding Wheel Speed (2 step) 1499:1600 rpm
Tailstock
Center travel 30mm
Center MT 4
Grinding Wheel Motor 5 HP
Machine Weight 1,914 lbs
Machine Footprint Size L x W x H 128" x 82.3" 69.3"
Equipped With
Automatic Grinding Cycle
Paper Filter & Magnetic Separator
Hydraulic Tailstock
FANUC 0i-TF Control
Grinding Wheel and g.w. flange
Wheel dresser
Splash Guard
Water Pump and Tank
2 point cent rest
touch probe gauge
X axis linear scale
Tool box
