Amps: 15 amps
Adjustable Set Point Range (Increasing):-
psid: 1-18
kPa: 6.9-124.1
bar: 0.069-1.24
Decreasing:-
psid: 0.4-17.4
kPa: 2.1-120.6
bar: 0.02-1.2
Deadband- Approximate: 0.6 psi, 4.14 kPa, 0.042 bar
System Pressure-Maximum: 400 psig, 2757.90 kPa, 28 bar
Proof Pressure:-
Both Ports: 750 psig, 5171.07 kPa, 52 bar
High: 750 psig, 5171.07 kPa, 52 bar
Low: 400 psig, 2757.90 kPa
Wetted Materials:
Pressure Ports: 1/4" FNPT Aluminum
Diaphragm: Polyamide
O-Ring: Viton
Relay: SPDT
