AC-1 Thermal Current (Ith): 60A
Voltage Rating: Up to 690V AC
Coil Voltage: 110V 50Hz / 120V 60Hz
DC Breaking Capacity: 250V DC, 63A Max
Horsepower Rating:
230V 3PH: 15 HP
460V 3PH: 30 HP
600V 3PH: 40 HP
Short-Circuit Current Rating (SCCR):
Basic: 10kA @ 480V (250A fuse)
High Fault: 100kA with Class J fuses
Impulse Withstand Voltage (Uimp): 8000V
Mounting: DIN Rail or Panel
Wire Size: AWG 14 to AWG 10
