Mazak QT-30 Lathe
| Swing | 20.8" | 528.32 mm |
| Machining Length | 39.76" | 1,009.9 mm |
| # Axis | 2 | 2 |
| Chuck Size | 12" | 304.8 mm |
| Bar Capacity | 2.7" | 68.58 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 3,300 RPM | 3,300 RPM |
| Turning Dia | 12.6" | 320.04 mm |
| Tailstock | Yes | Yes |
Swing: 20"
Swing Over Cross Slide: 15.8"
Max. Turning Length: 39.4"
Max. Turning Diameter: 12.5"
Boring Bar: 2"
Spindle Nose: 8" A2
Spindle Speed: 30 - 3,300 RPM
Spindle Motor: 26/30 HP
X-Axis Travel: 7.9"
Z-Axis Travel: 40.1"
Turret Type: Drum
Number of Turret Positions: 16
Chip Conveyor
