NEW DIMECO LINACUT

XL Series
- 15 ton single uncoiler with coil-car and line axis regulation.
- Precision straightener with 13 roller cassette and cleaning system.
- 3 kW XL-LINACUT with slat conveyor.
Cutting area : 2000 x 3000 mm (80” x 120”).
Unloading zone : 5 meters (16’).
- Gantry system for taylor made part sorting and stacking.
Double stacking table.

L Series
- 4.5 ton dual uncoiler.
- 11 straightening roll straightener.
- Dual head LINAPUNCH turret punch press with 4 cassettes
(including 2 multi index stations).
- 2kW L-LINACUT with slat conveyor.
Cutting area : 1000 x 1000 mm (40” x 40”).
- Gantry system with pallet conveyor system.
- 3 pallet slots .

M Series
- 4.5 ton single uncoiler.
- 11 roll straightener/feeder.
- 3kW M-LINACUT with slat conveyor.
Cutting area : 1000 x 1000 mm (40” x 40”).
- Sorting and stacking with FANUC 6 axis robot system.
- 3 slot pallet conveyor.

S Series
- 3 ton single uncoiler.
- 11 straightening roll straightener.
- 2 kW S-LINACUT without slat conveyor.
- Cutting area : 500 x 500 mm (20” x 20”).
- 8 meter long part (2,4’).
