All specifications are approximations and are subject to verification - these features according to original packing list
-UPGRADE Z-AXIS TRAVEL TO 42"
-UPGRADE SPINDLE MOTOR TO 35HP
-CTSPREP
-HIGH PRES COOLANT SYSTEM 8GPM 1200PSI 10 MICRON CHIPBLASTER
-LINK TYPE CHIP CONVEYOR (TWO PCS) W/FLUSHING DEVICE,
-FULL ENCLOSED SPLASH GUARD
-COOLANT SYSTEM
-AUTOMATIC LUBRICATION SYSTEМ
-AIR BLAST THROUGH SPINDLE
-REMOTE M.P.G. HANDWHEEL
-RS-232 INTERFACE
-THREAD MILLING ENABLED
-RIGID TAPPING ENABLE
| X | 80" | 2,032 mm |
| Y | 40" | 1,016 mm |
| Z | 42" | 1,066.8 mm |
| Power | 35 hp | 26.1 kW |
| RPM | 6,000 CPM | 6,000 CPM |
| # ATC | 32 | 32 |
| Taper | #50 | #50 |
| Table-W | 40" | 1,016 mm |
| Table-L | 80" | 2,032 mm |
| # Axis | 3 | 3 |
| Control | CNC (Fanuc 18iM CNC Control) | CNC (Fanuc 18iM CNC Control) |
| Dimensions | *see details* | *see details* |
| Weight | 30,000 | 30,000 |
Machine 18'6 x 12' x 11'2
Condensed Shipping 18'6" x 11'10" x 11'2"
2 Chip Pans x 12'6 x 80" stackable
1 Chip Blaster x 1' x 8" x 4'
2 Chip Conveyors x 8'5 x 4'
1 Operator Step 15' x 3'
