• 32 mm 1-1/4” Bar Capacity
• 6,000 RPM A2-5 Spindle
• 7.5 Horsepower
• Parts Catcher Standard
• Live Tooling Options
• 8-Station Turret Optional
| Swing | 12.59" | 319.79 mm |
| Machining Length | 5.5" | 139.7 mm |
| # Axis | 3 | 3 |
| Chuck Size | 5" | 127 mm |
| Bar Capacity | 32 mm | 1.2598" |
| Power | 7.5 hp | 5.6 kW |
| Max RPM | 6,000 RPM | 6,000 RPM |
| Turning Dia | 7.87" | 199.9 mm |
| Tailstock | No | No |
| Live Tooling | Yes | Yes |
| Sub Spindle | No | No |
| Weight | 4,850 lbs | 4,850 lbs |
