| X | 78.7" | 1,999 mm |
| Y | 35.4" | 899.16 mm |
| Z | 27.5" | 698.5 mm |
| # Axis | 5 | 5 |
| Power | 40 hp | 29.8 kW |
| RPM | 12,000 RPM | 12,000 RPM |
| # ATC | 48 | 48 |
| Taper | HSK 63A | HSK 63A |
| Table-W | 35.4" | 899.16 mm |
| Table-L | 84.6" | 2,148.8 mm |
| Dimensions | 209" X 130" X 157" | 209" X 130" X 157" |
| Weight | 46,297 | 46,297 |
SPECIFICATIONS:
CLAMPING AREA ........................84.6" X 35.4"
X-AXIS TRAVEL (TABLE MOVEMENT)..........78.7"
Y-AXIS TRAVEL (TABLE MOVEMENT)..........35.4"
Z-AXIS TRAVEL (HEADSTOCK MOVEMENT)......27.5"
DISTANCE FROM TABLE TOP TO
SPINDLE FACE IN VERTICAL POSITION ......3.1" TO 30.7"
A-AXIS SWIVELING RANGE................± 40°
B-AXIS ROTATING RANGE (TABLE).........± 40°
MAXIMUM TABLE LOAD......................4,850 LB
SPINDLE DRIVE MOTOR ....................40 HP
SPINDLE OUTPUT TORQUE ..................811 FT-LB
SPINDLE TAPER...........................HSK63A TAPER
SPINDLE SPEED ..........................12,000 RPM DIRECT DRIVE
SPINDLE TYPE............................DIRECT DRIVE
RAPID FEEDRATE (X AND Y AXES)...........944 IPM
RAPID FEEDRATE (Z AXIS).................708 IPM
MAXIMUM CUTTING FEEDRATE................394 IPM
TOOL STORAGE CAPACITY...................48 ATC
STANDARD FLOOR SPACE....................209" X 130" X 157"
FANUC 31I B5
COOLANT SYSTEM AND TANK W/ 420 LTR. CAP.
DRUM FILTER TYPE CHIP CONVEYOR
BED FLUSHING
FINISH AND ALARM LAMP
HEAT EXCHANGER
MPG REMOTE HANDWHEEL
MAGNETIC SCALE ON X, Y, AND Z AXES
WORK LIGHT
RS-232 INTERFACE
ROOF ENCLOSURE GUARDING SYSTEM
MAGNETIC ROTARY ENCODER OF A / B AXES
