Minster 30 Ton Piecemaker Mechanical Press, P2-30-30, 30" x 19" bed area, 2" stroke, 400 SPM, 12.5" Shut Height
| Tonnage | 30 T | 27.216 t |
| Stroke | 2" | 50.8 mm |
| Shut Height | 12.5" | 317.5 mm |
| Bed area (Left to right) | 30" | 762 mm |
| Bed area (Front to back) | 19" | 482.6 mm |
| SPM min. | 0 strokes/min. | 0 strokes/min. |
| SPM max. | 400 strokes/min. | 400 strokes/min. |
| Adjustment | 2" | 50.8 mm |
| Windows Width | 7.5" | 190.5 mm |
| Weight | 13000 | 13000 |
Model Number: P2-30-30
Serial Number: P2-30-29577
Year of Manufacture: 1999
Bed Area: 30” x 19”
Slide Area: 30” x 14”
Stroke: 2”
Shut Height to Bed: 12.5” SDAU over bed
Bolster Thickness: 3”
Strokes per Minute: 400
Adjustment: 2”
Windows: 7.5” wide
Approximate Overall Weight: 13,000 lbs
Air Clutch and Brake Assembly
T-Slotted Bolster and Slide Assembly
Minster Cabinet Mounted Press Controls
Single/Inch/Continuous
Palm Buttons
Air Counterbalances
Minster Monitor Flow Lube System
Vibration Isolation Levelers
28-CFC Minster Clutch
Dynamatic Variable Speed Motor
8 Point Gibbing
