AIDA MECHANICAL PRESS, MODEL NC1-200(1)

MODEL: NC1-200(1)

ITEM ID: NC1-200-UJ

SERIAL #: 10220-6837

CAPACITY: 220 TON

BLANKING CAPACITY: 176 TON

SLIDE STROKE: 6.29"

STROKES PER MINUTE: 35-70

DIE HEIGHT: 16.14" (to top of bolster)

SLIDE ADJUSTMENT: 4.33" (motorized)

SLIDE AREA: 34.6" L-R, 25.5" F-B

BOLSTER AREA: 54.7" L-R, 26.7" F-B

MOTOR: 20 HP

WEIGHT: 45,000 LBS

DIMENSIONS (LxWxH): 102" x 67" x 144"

LOCATION: OHIO, USA
