| X | 39.3" | 998.22 mm |
| Y | 31.5" | 800.1 mm |
| Z | 29.5" | 749.3 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 4,500 RPM | 4,500 RPM |
| # ATC | 60 | 60 |
| Taper | #50 | #50 |
| Pallet-W | 24.8" | 629.92 mm |
| Pallet-L | 24.8" | 629.92 mm |
| # Axis | 3 | 3 |
| Control | CNC (Mazatrol M-32) | CNC (Mazatrol M-32) |
| Weight | 37,400 | 37,400 |
Pallet Size: 24.8" x 24.8"
Table Load Capacity: 2,640 Lbs.
X-Axis Travel: 39.3"
Y-Axis Travel: 31.5"
Z-Axis Travel: 29.5"
Distance, Spindle Center to Table Top: 1.97" - 33.5"
Distance, Spindle Nose to Table Center: 7.87" - 37.4"
Rapid Traverse Rate: 781 I.P.M.
Spindle Speeds: 22 to 4,500 Rpm
Tool Magazine Capacity: 60
Spindle Motor: 30 Hp
Machine Weight: 37,400 Lbs.
Twin Pallets
Mazatrol M-32 Cnc Control
Manual Pulse Generator
Chip Conveyor
