OSP200M Control
Thru spindle coolant
Full 4th axis
15k spindle
64 atc
Chip conveyor
Includes 6 tombstones
All manuals
| size | 16 X 16" | 16 X 16" |
| X | 22" | 558.8 mm |
| Y | 24" | 609.6 mm |
| Z | 22" | 558.8 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 60 | 60 |
| Control | CNC (OSP 200M) | CNC (OSP 200M) |
Pallet W x L: 15.75" x 15.75"
Pallet Load Capacity: 880 LBS
X-Axis Column Longitudinal Travel:. 22.05"
Y-Axis Head Vertical Travel: 24.02"
Z-Axis Table Cross Travel: 24.61"
Spindle-Center to Table-Top, Minimum: 1.97"
Spindle-Center to Table-Top, Maximum: 25.98"
Spindle Taper: #40 NT
Spindle Speeds Range, Infinitely Var: 50 to 8000 RPM
Rapid Traverse Rate: 1970 IPM
Spindle Motor: 20 HP
Floor Space Required, L x W: 14'9" x 7'11"
Weight, Approximately: 25080 LBS
OSP200M Control
Thru spindle coolant
Full 4th axis
15k spindle
64 atc
Chip conveyor
Includes 6 tombstones
All manuals
