MACHINING SYSTEMS HMC 200 4 PALLET MACHINING CENTER WITH EXTENDED Y TRAVEL
| size | 120" x 72" | 120" x 72" |
| X | 60" | 1,524 mm |
| Y | 72" | 1,828.8 mm |
| Z | 58" | 1,473.2 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 3,000 RPM | 3,000 RPM |
| # ATC | 48 | 48 |
| Taper | 50 | 50 |
| Pallet-W | 39" | 990.6 mm |
| Pallet-L | 39" | 990.6 mm |
| # Axis | 3 | 3 |
| Control | CNC (GE Fanuc 18iM) | CNC (GE Fanuc 18iM) |
• Fanuc 18i-M controller
• 4 station pallet changer
• 48 tool ATC
• CAT50 spindle, 30hp
• Built in 2004, Installed early 2005
