X2nd Turret Live Tooling: false
X4th Axis: false
X5th Axis: false
Additional Machine Specs: Equipped with:
1. Workable bar length maximum 13.45' (4,100mm)- minimum 3.94' (3,000mm)
2. Bar diameter maximum 3.150" (80mm) - minimum 7.87" (20mm)
3. Capacity storage: Forklifter 700mm
4. Color: dark gray RAL7021 light grey RAL7038
5. Completely managed by touch screen PLC
6. Fully automated
7. Complete diagnostics with display of entries and exits
8. Programmable bar length
9. Feed, speed, and pusher thrust controlled by brushless motor
10. Bar diameter controlled by PLC
11. Rear extraction by means of a self-centering and self-regulating ejector
12. Guided channels made of Vulcanized plastic material
Bar Capacity: 3.15
Bar Length: 161.4
B Axis: false
C Axis: false
Live Milling Thru Spindle Coolant: false
Live Tooling Milling: false
Machine Used On: Puma 2600SYII
Programmable Tailstock: false
Single Turret: false
Single Turret Live Tooling: false
Sub Spindle: false
Tailstock: false
Twin Turret: false
Y Axis: false
