X2nd Turret Live Tooling: false
X4th Axis: false
X5th Axis: false
B Axis: false
C Axis: false
Chip To Chip Time: 4.5
Control Make Model: Haas CNC Control
Cutting Feed Rate: 650
Live Milling Thru Spindle Coolant: false
Live Tooling Milling: false
Max Table Pallet Load: 1500.0
Max Tool Diameter: 2.5
Max Tool Diameter Adjacent: 5.0
Max Tool Length: 11.0
Max Tool Weight: 12.0
Probe Make Model: Renishaw Probe
Programmable Tailstock: false
Rapid Traverse: 1000
Rotary Make Model: Haas TRT-210 4th Axis
Rotary Table Trunnion: 4th Axis
Single Turret: false
Single Turret Live Tooling: false
Spindle Motor: 20
Spindle Nose To Table Top: 4-24
Spindle Speed: 8000.0
Spindle Taper Type: CAT#40
Sub Spindle: false
Tailstock: false
Tool Changer Type: Carousel
Tool Change Time: 4.2
Tool Magazine Capacity: 24.0
Twin Turret: false
Vertical Table Pallet Size: 36" x 14
X Travel: 30.0
Y Axis: false
Y Travel: 16.0
Z Travel: 20.0
