X2nd Turret Live Tooling: false
X4th Axis: false
X5th Axis: false
Additional Machine Specs: Inline Direct Drive Spindle
B Axis: false
C Axis: false
Chip Removal: Chip Auger
Chip To Chip Time: 2.4
Control Make Model: Haas CNC Control
Control Options: Color Monitor, High Speed Machining, Remote Jog Handle
Cutting Feed Rate: 833
Live Milling Thru Spindle Coolant: false
Live Tooling Milling: false
Machine Options: Auto Door, High Intensity Lighting, Worklight
Max Table Pallet Load: 1500.0
Max Tool Diameter: 2.5
Max Tool Diameter Adjacent: 5.0
Max Tool Length: 11.0
Max Tool Weight: 12.0
Probe Make Model: Renishaw Probe
Programmable Tailstock: false
Rapid Traverse: 1400
Rotary Table Trunnion: Wired for 4th Axis
Single Turret: false
Single Turret Live Tooling: false
Spindle Motor: 30
Spindle Nose To Table Top: 4-24
Spindle Speed: 12000.0
Spindle Taper Type: 40 Taper
Sub Spindle: false
Tailstock: false
Tool Changer Type: Side Mount
Tool Change Time: 1.8
Tool Magazine Capacity: 24.1
Twin Turret: false
Vertical Table Pallet Size: 36" x 14
X Travel: 30.0
Y Axis: false
Y Travel: 16.0
Z Travel: 20.5
