X2nd Turret Live Tooling: false
X4th Axis: false
X5th Axis: true
Additional Machine Specs: Travels:
- X2 Axis: 6.6"
- XB Axis: 4.72"
- Y1 Axis: 4.13"
- Y2 Axis: 4.13"
- Z2 Axis: 27.9"
- ZB Axis: 28.3"
(4) Live Tool Holders
Bar Capacity: 2.68
B Axis: false
C Axis: false
Chip Removal: Chip Conveyor
Chuck Size: 8.0
Control Make Model: Fanuc 31i CNC Control
Distance Between Centers: 35.44
Live Milling Hp: 10
Live Milling Thru Spindle Coolant: false
Live Tooling Milling: true
Max Cutting Turning Diameter: 9.0
Max Swing Over Bed: 9.0
Max Swing Over Cross Slide: 9.0
Max Turning Cutting Length: 26.0
Programmable Tailstock: false
Second Spindle Motor: 25
Single Turret: false
Single Turret Live Tooling: false
Spindle Bore: 2.99
Spindle Motor: 25
Spindle Nose: A2-6
Spindle Speed: 5000.0
Sub Spindle: true
Tailstock: false
Tool Change Time: 0.15
Tool Positions: 12.0
Turret Max Rpm: 5000
Turret Options: Boring Bar Diameter: 1.5"
Turning Tool Shank: 1"
Twin Turret: true
X Travel: 8.54
Y Axis: true
Z Travel: 27.9
