USED 2015 KNUTH VERTURN VDM1600 CNC VBM
Overview
Description
Knuth Model Verturn VDM1600 55" CNC Vertical Turning Center (2015), 55" Table, 63" Swing, 47" Max Height, 4 Position Turret, Siemens 828 D SL CNC
Specifications
| Chuck / Table Dia | 55" | 1,397 mm |
|---|---|---|
| Swing | 63" | 1,600.2 mm |
| Maximum Cutting Diameter | 55 in | |
| Work Ht-U/R | 47" | 1,193.8 mm |
| Vertical Travel X | 40 in | |
| Horizontal Travel Z | 30 in | |
| RPM | 200 RPM | 200 RPM |
| Power | 60 hp | 44.7 kW |
| Control | CNC (Siemens 828 D SL CNC) | CNC (Siemens 828 D SL CNC) |
Knuth Model Verturn VDM1600 55" Vertical Turning Center
Turning Dia: 63"
Machining Height: 47"
X Axis Travel: 40"
Z Axis Travel: 31"
W Axis Travel: 33"
Work Piece Weight (max): 11,000 lbs
Headstock
Speed Range: .5 - 200 RPM
Torque Max: 23,600 ft lb
Lathe Chuck Dia: 55"
Feed
Rapid Feed X axis: 236 IPM
Rapid Feed Z axis: 236 IPM
Feed W axis: 17 IPM
4 Position Turret
Tool Change Time: 10S
Tool Weight: 55 lbs
Main Motor Drive: 60 HP
Equipped With
Siemens 828 D SL CNC
4 Position Turret
Chip Conveyor
Coolant System
