| X Axis Travel | 62.99" | 1,599.9 mm |
| Y Axis Travel | 35.43" | 899.92 mm |
| Z Axis Travel | 31.49" | 799.85 mm |
| Cutting Feed Rate | 314 IPM | 314 IPM |
| Rapid Traverse X | 787 in/min. | 1,999 cm/min. |
| Rapid Traverse Y | 787 in/sec. | 119,938.8 cm/min. |
| Rapid Traverse Z | 590 in/min. | 1,498.6 cm/min. |
| Distance From Spindle To Column | 3.93″ – 35.43″ | 3.93″ – 35.43″ |
| Spindle Motor | 20 hp | 14.9 kW |
| Spindle Speed | 10,000 RPM | 10,000 RPM |
| ATC Capacity | 30 | 30 |
| Spindle Taper | 40 | 40 |
| # Axis | 3 | 3 |
| Table-W | 33.46" | 849.88 mm |
| Table-L | 66.93" | 1,700 mm |
| Max. Table Load | 4,410 Lbs | 4,410 Lbs |
| Dimensions | 152″ x 144″ x 132″ | 152″ x 144″ x 132″ |
| Weight | 41,887 Lbs | 41,887 Lbs |
Fanuc 18i-MB CNC Control
Rigid Tapping
Spindle Chiller Unit
MPG Hand Wheel Control
Table Riser Block
Dual Chip Auger
