| Tonnage | 60 T | 54.431 t |
| Stroke | 3" | 76.2 mm |
| Shut Height | 13.5" | 342.9 mm |
| SPM | 0 strokes/min. | 0 strokes/min. |
| Vari Speed (Yes/No) | 'Yes' | 'Yes' |
| Bed W | 25" | 635 mm |
| Bed L | 36" | 914.4 mm |
• Tonnage = 60
• Stroke = 3.00″
• Speed (Variable) = 100-250 SPM
• Slide Adjustment = 3.125″
• Shut HT (S.D.A.U.) = 13.5″
• Bed Area = 36″ R-L x 25″ F-B
• Slide Area = 36″ R-L x 15″ F-B
• Side Window Width = 12″
• Motor = 15 HP
• Electric = 230/460V/60HZ/3PH
• Weight (Approx.) = 15,000 lbs
• Air Clutch and Brake
• Dual Air Counterbalances
• Automatic Recirculating Lubrication System
• Shut Height Indicator
• Eight Point Gibbing
• Tie Rod Construction
• Eddy Current Motor
• 4″ Bolster (Center Cutout: 30″ L-R x 6″ F-B)
• (4) Isolation Mounts
May be seen under power on our floor
