Alpine 75AEMR-LR All Electric Tube Bender

The Alpine 75AEMR-LR all-electric tube bender introduces unmatched capabilities for bending tubes up to 75mm, merging superior performance with sustainable practices. Designed for high-demand applications, this machine is the answer for industries pushing the limits of bending large diameters with absolute precision.
Key Features:
Superior Bending Capacity: Handles tubes up to 75mm, supporting complex bending requirements with ease.

All-Electric Efficiency: Delivers precise, repeatable bends with an eco-friendly footprint, significantly reducing energy consumption.

Advanced Control: Utilizes a state-of-the-art servo system for precise movement control, ensuring optimal bending accuracy.

Sustainable Operation: Emphasizes green manufacturing principles, eliminating the need for hydraulic fluids and minimizing waste.

Standard Machine and Accessories
Master IV Controller with 15″ color LCD Touch Screen for easy programming.
Supports Right and Left Hand Bending and Multi Stack Tooling.

Patented Direct Drive A/C Servo Motor Bending Head reduces interference.
Includes tools for measuring push or roll bending radius.

Unlimited Program Storage, Metric and Inch setting, and XYZ to YBC conversion.

Pressure Die assist (booster not included in the 30 model) and Independent programmable speeds for Y, B, and C axes.
Features Air Cooling System, Automatic Slide-way Lubrication, Foot Pedal Cycle Start, Wiper Die Bracket, and 3 Mandrel Rods.
Comes with an Operation and Maintenance Manual, Tool Box with Tools, customizable Electric Specs (3 phase 208V, 220V, 480V), and a Safety Mat.
Upgrade Options
AMRU (Anticipate Mandrel Retraction Unit) and AML (Auto Mandrel Lubrication) for enhanced performance.

Dynamic Visual Simulation Software for collision protection.
Options for Safety Mat Connection, CE Mark, Safety Scanner, and a Free Standing Pedestal to replace the foot pedal.
