NEW SUN FIRM SET 36120

One-piece machine bed which is most suitable for heavy duty machining

Capacity
Swing Over Bed 930 mm (36")
Swing Over Cross Slide 700 mm (27-1/2")
Swing in Gap 1200 mm (47")
Width of Gap 225 mm (8-7/8")
Width of Bed 460 mm (18-1/8")
Distance Between Centers 1500 mm (60")

Headstock
Spindle Bore 6"
Spindle Nose A2-11
Taper of Center M.T. No. 5
Range of Spindle Speeds 15-1000
Number of Spindle Speeds 12 Changes

Feeds & Threads Cutting
Longitudinal Feeds 0.05-0.7 mm/rev
Cross Feeds 0.025-0.35 mm/rev
Inch Threads 2-28 Thread/in, (D.P. 4-56)
Metric Threads 0.8-14 mm / Thread, (M.P. 0.5-7)
Leadscrew Ø 45 mm (1-3/4") x 2 T.P.I.

Carriage
Cross Slide Travel 425 mm (16-1/2")
Compound Rest Travel 250 mm (10")

Tailstock
Quill Diameter 105 mm (4-1/8")
Quill Travel 230 mm (9")
Taper of Quill Center M.T. No.5
