| Dimensions | 6.19′ L x 1.68′ W x 3.81′ H / 1.88m x 0.51m x 1.16m | 6.19′ L x 1.68′ W x 3.81′ H / 1.88m x 0.51m x 1.16m |
| Weight | 1550 lbs / 703.06 Kg | 1550 lbs / 703.06 Kg |
Swing Over Bed: 13 in. / 330.2 mm
Swing Over Cross Slide: 7.6 in. / 195 mm
Swing Over Gap: 19 in. / 490 mm
Gap Width (In Front Of Face Plate): 9.43 in. / 240 mm
Distance Between Centers: 40 in. / 1016 mm
Spindle Speed: 40 – 2000 RPM
No. of Spindle Speeds: Variable (high/low)
Spindle Nose: D1-4 camlock
Spindle Bore: 1.56 in. / 39.62 mm
Threads (Inch/Metric): 2 – 56 tpi / 0.5 – 12 mm
Longitudinal Feeds: 0.0016 – 0.046 in. / 0.0406 – 1.168 mm
Cross Feeds: 0.0005 – 0.015 in. / 0.0127 – 0.381 mm
Leadscrew Pitch, Diameter: 8 tpi, 0.87 in.
Cross Slide Travel: 6.18 in. / 157 mm
Compound Travel: 3.75 in. / 95 mm
Compound Width: 4.5 in. / 114.3 mm
Bed Length: 64 in. / 1625.6 mm
Bed Width: 8.5 in. / 206 mm
Quill Diameter: 1.56 in. / 39.62 mm
Quill Travel: 4 in. / 101.6 mm
Quill Center Taper: MT #3
Spindle Motor: 3 HP / 2.23 KW
Voltage: 220V/440V
Phase: 3 Phase
Power Consumption (220V): 3 KVA / 10 amps
Power Consumption (440V): 3 KVA / 5 amps
Standard Accessories: 3-jaw 8″ chuck, steady rest, Removeable gap, back plate, Coolant system, 4 way toolpost, Full length splash guard, Center sleeves, dead center, tool kit, wired 220V, for 440V, need new motor, or transformer, Can run on single phase motor
Optional Accessories: 3-jaw chuck, different sizes, 4-jaw chuck, different sizes, Chuck guard w/ limit switch, Follow rest, Roller jaw set for steady rest, Taper attachment, Quick change tool holder set (7 pcs. Holder), Live center – MT#3, Drill & arbors, Face plate (12″), 4-way carriage stop, Micrometer carriage stop safety cover on end of spindle, Halogen work light, tool guard (at front of compound slide with limit switch), Lead screw cover (accordion style), 5C collet set (1/8″ to 1-1/16″ by 1/16″) 16 pcs., 5C lever collet closer
