| X Axis | 95" | 2,413 mm |
| Y Axis | 67.7" | 1,719.6 mm |
| Z Axis | 39" | 990.6 mm |
| A-Axis | +/- 105° | +/- 105° |
| C-Axis Rotation | +/- 370° | +/- 370° |
| Power | 38.9 hp | 29 kW |
| RPM | 20,000 RPM | 20,000 RPM |
| # ATC | 24 | 24 |
| Taper | HSK63 | HSK63 |
| Table-W | 63" | 1,600.2 mm |
| Table-L | 90" | 2,286 mm |
| Max. Table Load | 48,400 lb | 21,953.9 kg |
Heidenhain iTNC 530 CNC Control
High Pressure Coolant System
Chip Conveyor
