NEW 2026 AMADA SDEW-3025

SDEW Series Presses incorporate the same innovative features as the SDE Series in a wide bed, two point design. These machines are a servo press solution for larger tools that are capable of operations such as blanking, fine blanking, deep drawing, coining etc. – in one machine. The efficient energy management system of the SDEW press not only saves energy, it also reduces operating costs by only using full power when needed.

The productivity and efficiency of our new systems are unique to AMADA presses and represent our continued commitment to innovation and providing our customers industry leading solutions.

SDEW Series servo presses are the ideal replacement for both mechanical AND hydraulic press systems. The characteristics of our servo technology incorporate the best aspects of mechanical and hydraulic forming providing users greater flexibility to their production capabilities and increased profitability.

The SDEW Series is a straight side design with capacities of 200 and 300 tons with a range of bed areas to meet a wide array of product manufacturing needs.

NEW AMADA MODEL SDEW-3025-i3
SPECIFICATIONS:
Tonnage (Short Ton) 330 US Tons
Rating point, above BDC .196”
Die Height (over bolster), SDAU 21.6”
Die Height Adjustment (AUTOMATIC) 4.72”
Strokes per minute at 9.84” stroke length ~45 SPM
Pendulum Motion Speed: Available on request
Max. Stroke Length 9.84”
Slide Area, -- 78.74” L.R. x 27.55”
Gibs, Type-Square (Full Length / Long Gibs) -- 6 Point
Automatic Oil Recirculating System
Bed/Bolster Area, -- 94.4” L.R. x -- 37.4” F.B.
TECHNOLOGY:
CONTROL: Amada i3 Control System
Operator Pendant Control panel: 12.1” Color LCD Touch Screen
Portable Two-Hand Control Pendant
