320-18 CINCINNATI-MILACRON "HIGH-POWER DIAL-TYPE"
PLAIN HORIZONTAL MILL & INDEPENDANT OVERHEAD
SPINDLE VERTICAL HEAD
Serial No 31053P5Y-11, Model 320-18, Ltr LA,
| Table Size-W | 18" | 457.2 mm |
| Table Size-L | 72" | 1,828.8 mm |
| Travel-Long | 34" | 863.6 mm |
| Travel-Cross | 12" | 304.8 mm |
| Travel-Vert | 20" | 508 mm |
| Power | 20 hp | 14.9 kW |
| RPM | 1,600 RPM | 1,600 RPM |
| Taper | #50 NSTD | #50 NSTD |
| Dimensions | 116 x 118 | 116 x 118 |
| Weight | 14000 | 14000 |
320-18 CINCINNATI-MILACRON "HIGH-POWER DIAL-TYPE"
PLAIN HORIZONTAL MILL & INDEPENDANT OVERHEAD
SPINDLE VERTICAL HEAD
Serial No 31053P5Y-11, Model 320-18, Ltr LA,
EQUIPPED WITH:
Independant Overarm I.O.S Vertical Head
Knee Motor
Front & Rear Controls
Coolant System (Built-In)
CATALOG SPECIFICATIONS:
Table Dimensions (Overall), W x L 18" x 72"
Table Working Surface, W x L 18" x 72"
Table Longitudinal Travel (X-Axis) 34"
Saddle In-Out Cross Travel (Z-Axis) 12"
Knee Vertical Travel (Y-Axis) 20"
Spindle-Center to Table-Top, Minimum 0"
Spindle-Center to Table-Top, Maximum 20-13/16"
Spindle Taper #50 NSTD
(24) Spindle Speeds, Range 16 to 1600 RPM
Vertical Spindle Speeds, Range 147 to 1502 RPM
(32) Longitudinal and Cross Feeds 3/8 to 90 IPM
(32) Vertical Feeds, Range 3/32 to 22.5 IPM
Power Rapid Traverse, Long & Cross 150 IPM
Power Rapid Traverse, Vertical 37-1/2 IPM
Spindle Motor, Horsepower 20 HP
Knee Motor, Horsepower 3 HP
Floor Space Required, W x D 116" x 118"
Weight, Approximately 14000 LBS
F.O.B. OUR WAREHOUSE
