2" x 2" x 1/4" ROUNDO HYDRAULIC HORIZONTAL ANGLE BENDING ROLL
New 2006, Serial No 06815, Model SR-2
| Angle (L1) | 2" | 50.8 mm |
| Angle (L2) | 2" | 50.8 mm |
| Angle (T) | 0.25" | 6.35 mm |
| Pipe Capacity | 2" | 50.8 mm |
| Hyd/Mech | 'HYD' | 'HYD' |
| Operation (Horz, Vert, Horz/Vert) | 'HORZ' | 'HORZ' |
| Dimensions | 3' x 2'7" | 3' x 2'7" |
| Weight | 1765 LBS | 1765 LBS |
2" x 2" x 1/4" ROUNDO HYDRAULIC HORIZONTAL ANGLE BENDING ROLL
New 2006, Serial No 06815, Model SR-2
EQUIPPED WITH:
Leg In - Leg Out
Hydraulic Roll Adjustment
Set of Rolls On Machine
Hand Held Pendant Control
CATALOG SPECIFICATIONS:
Bending Capacity at Minimum Diameter:
Leg-In Angles, Angle Sides 2" x 2"
Leg-In Angles, Angle Thickness 1/4"
Leg-Out Angles, Angle Sides 2" x 2"
Leg-Out Angles, Angle Thickness 5/16"
Flat On Flat 5" x 5/8"
Flat On Edge 2-1/4" x 1/2"
Solid Round Bars 1-5/16"
Solid Square Bars 1-1/4"
Standard Pipe 2"
Bending Rolls, Diameter 7-1/2"
Floor Space Required, W x D 3' x 2'7"
Weight, Approximately 1765 LBS
F.O.B. OUR WAREHOUSE
