High-Speed, High-Precision Machining for Aluminum & Cast Iron Components
The THA-4000P is a cutting-edge CNC horizontal turning center engineered for efficient, high-precision machining of aluminum and cast iron parts. With a compact footprint and a powerful 15,000 rpm direct-drive spindle delivering up to 249 Nm of torque, this machine is optimized for both performance and productivity in high-volume manufacturing environments.
Designed for applications requiring smaller strokes, the THA-4000P features a rigid structure with stepped-bed X-axis roller guideways, a 3-point support system for stability, and a minimized width ideal for mass production line integration. The optional APC (Automatic Pallet Changer) dramatically reduces loading and unloading times, while high-speed ATC, thermal displacement compensation, and flexible automation options maximize uptime and accuracy.
Key Features:
• Spindle: 15,000 rpm direct-drive spindle (opt. 20,000 rpm), 37/15 kW power
• Travel & Speed: X/Y/Z stroke of 610/610/660 mm with rapid traverse of 60 m/min
• B-axis Table: 0.001° indexing, Ø630 × H800 mm workpiece capacity
• Automation Ready: Optional APC, tool & workpiece measuring systems, and full FMS integration
• Compact & Rigid: Stepped bed and honeycomb column structure for enhanced rigidity and thermal stability
• Eco-Efficient: Energy-saving design with reduced coolant, lubricant, and power consumption
• Built for modern production demands, the THA-4000P combines speed, accuracy, and flexibility to meet the rigorous needs of the automotive, aerospace, and general machining industries.
| X-Axis Travel | 610 mm | 24.016" |
| Y-Axis Travel | 610 mm | 24.016" |
| Z-Axis Travel | 660 mm | 25.984" |
| Table Height From Floor | 1,150 mm | 45.276" |
| Max Workpiece Height | 800 mm | 31.496" |
| Spindle Center To Working Table Surface | 690 mm | 27.165" |
| Spindle Nose To Working Table Center | 730 mm | 28.74" |
| Table Size - X | 400 mm | 15.748" |
| Table Size - Y | 400 mm | 15.748" |
| Table Capacity | 400 kg | 881.8 lb |
| Spindle Speed | 15,000 RPM | 15,000 RPM |
| Spindle Taper | CAT40 | CAT40 |
| Tool Magazine Capacity | 40 | 40 |
| Tool Length | 410 mm | 16.142" |
| Tool Weight | 10 kg | 22 lb |
| Max Tool Dia | 80 mm | 3.1496" |
FANUC 0i-MF PLUS WITH15" LCD MONITOR
FANUC AICCII (400 BLOCK) + 2GB DATA SERVER
SPINDLE CENTER TO WORKING TABLE SURFACE 80~690 MM
SPINDLE NOSE TO WORKING TABLE CENTER 70~730 MM
15,000 RPM DIRECT DRIVEN SPINDLE, CAT40 BIG PLUS
SPINDLE MOTOR 37/15 KW
40 TOOLS – AUTOMATIC TOOL MAGAZINE
SPINDLE COOLER
B AXIS MIN. INDEXING INCREMENT 0.001 DEGREE
20 BAR COOLANT THROUGH SPINDLE SYSTEM WITH HIGH PRESSURE PUMP AND FILTER SYSTEM
APC (ROTARY TYPE) WITH TWO (2) WORKING TABLE
COOLANT UNIT
MACHINE ROOF OVERHEAD COOLANT FLUSHING SYSTEM
CHIP CONVEYOR (SCRAPER TYPE) H=1100 MM WITH TROLLEY
CENTRAL LUBRICATION FOR X/Y/Z AXIS
TELESCOPIC COVERS FOR X/Y/Z AXIS
STANDARD FULL SPLASH GUARD
ELECTRICAL CABINET WITH HEAT EXCHANGER
OIL SKIMMER (DISC TYPE)
MANUAL PULSE GENERATOR
THREE COLOR WARNING LAMP
WORK LIGHT (LED)
DOOR INTERLOCK
RIGID TAPPING
COOLANT GUN
AIR GUN
