Heidenhain HR 550 CNC ControlRobi 105 Automatic Tool ChangerRenishaw RMP 60 HandwheelControl panel Vertical console with integrated keyboard and 15-inch LCD screenMaster-slave system, max. load 20 t, ROD encoder on the B-axisHeidenhain optical linear system, absolute for the V, W, X, Y, and Z axesMachine with increased accuracyControl cabinet with air conditioningAutomatic lubrication systemAutomatic clamping of accessory headsHydraulic equipmentCooling unit for spindle bearings for temperature stabilizationChip conveyor as segment conveyor with integrated pump for coolant circulation (including level gauge and filtration)CNC adjustable with paper belt filterSump pump with level gaugeManual milling head UHM 30 with automatic clamping
Manufacturer: Fermat
Model: WFT 13 R
Year: 2017
Condition: Used
Stock Number: 552374
Spindle diameter: 130 mm
Spindle speeds: 4,000 rpm
X axis travel: 4,000 mm
Y axis travel: 3,000 mm
Z axis travel: 1,500 mm
W axis travel: 730 mm
V axis travel: 700 mm
Table dimensions: 2,000 x 3,000 mm
Table capacity: 25,000 kg
Spindle taper: SK 50/ISO 50 DIN 69871 Form AD
Rapid traverse: 20,000 mm/min
Main drive: Siemens 41 kW S1 kW
Rapid traverse V axis: 10,000 m/min
Spindle support: 250 mm
Ejection height: 900 mm
