Daewoo Doosan Puma 300LC CNC Turning Center, Fanuc 21i-TB CNC Control, 23" Swing, 12" 3-Jaw Chuck, Tailstock with 52" Centers, Steady Rest, 12 Position Turret, 35 HP, 2800 RPM, Chip Conveyor & Coolant System, New 2006.
| CNC Control | Fanuc 21i-TB CNC | Fanuc 21i-TB CNC |
| # Axis | 2 | 2 |
| Max Swing Over Bed | 23" | 584.2 mm |
| Max Swing Over Saddle | 14.5" | 368.3 mm |
| Max Turning Length | 50.4" | 1,280.2 mm |
| Chuck Size | 12" 3-Jaw | 304.8 mm |
| Max Distance Between Centers | 52.8" | 1,341.1 mm |
| X-Axis (Cross Travel) | 11.1" | 281.94 mm |
| Z-Axis (Longitudinal Travel) | 52.4" | 1,331 mm |
| X-Axis Rapid Traverse Rate | 787 in/min. | 20 m/min. |
| Z-Axis Rapid Traverse Rate | 945 in/min. | 24 m/min. |
| Sub Spindle | No | No |
| # Tool Turrets | 1 | 1 |
| Tool Turret Positions | 10 | 10 |
| Live Tooling | No | No |
| Spindle Nose | A2-11 | A2-11 |
| Spindle Bore | 4.53" | 115.06 mm |
| Bar Capacity | 4" | 101.6 mm |
| Spindle Speed Range | 10 - 2,800 RPM | 2,800 RPM |
| Spindle Power | 35 hp | 26.1 kW |
| Tailstock | Yes | Yes |
| Tailstock Taper | #5 MT | #5 MT |
| Tailstock Quill Travel | 4.7" | 119.38 mm |
| Tailstock Quill Diameter | 3.97" | 100.84 mm |
| Electrics | 240/3/60 | 240/3/60 |
| Dimensions | 168" x 77" x 80" | 168" x 77" x 80" |
| Weight | 18,000 LBS | 18,000 LBS |
Fanuc 21i-TB CNC Control, RS-232 Port, 12" 3-Jaw Samchully H212 Hydraulic Chuck, 4" Bar Capacity, Turn Through Steady Rest, Automatic Tool Presetter, 12 Position Turret, Tailstock with Programmable Quill, Foot Pedals, Chip Conveyor, Coolant System.
