| Tonnage | 110 T | 99.79 t |
| Type | HYD | HYD |
| Overall Length | 157.48" | 4 m |
| Between Housings | 122.05" | 3.1 m |
| Stroke | 3.94" | 100.08 mm |
| # Axis | 3 | 3 |
Nominal rated capacity: 110 Tons
Bending capacity: 118" X 3/16" or 84" X 1/4" (mild steel)
Overall length of bed and ram: 13' 2" (158")
Distance between housings: 10' 2" (122")
Depth of throat: 15.7"
Length of stroke: 0" to 3.9" (adjustable)
Open height: 14.8"
Rapid approach speed: 139 IPM
Pressing speed: 23.4 IPM
Rapid return speed: 122.4 IPM
Hydraulic pump motor: 10 HP AC
CNC Type: Amada NC9-EX
NC9EX Cnc Back Gauge
