FEATURES:
• Allows for straight cutting and miter cutting from 0 to 60 degrees
• Hydraulic cylinder supports the saw head with ball joint
• Gearbox designed to accept high lateral pressure (no thermal distortion)
• Inverter blade drive system which allows infinitely variable blade speeds
• 5.7” HMI touchscreen
• Adjustable flood coolant system
• Motor driven, synchronized wire blade brush
• Carbide blade guides and bearings provides additional blade support
• Rigid cast-iron guide arms
• Automatic hydraulic blade tensioning device
• Cast-iron hydraulic vise
• Save-A-Blade feature
• Precision feed pressure and feed rate dual valve system for optimal cutting performance
• Computer controlled multiple indexing up to 999” max length
| Rect-Cap (H) | 13" | 330.2 mm |
| Rect-Cap (W) | 20" | 508 mm |
| Rounds-Cap | 14" | 355.6 mm |
| Type (Auto, Manual, Semi) | 'Auto' | 'Auto' |
Blade Speed 50 - 328 FPM
Blade Size (LxWxT) 16' 1" x 1.25" x .042"
Blade Motor 5 HP
Coolant Motor 1/8 HP
Coolant Tank Capacity 16.1 gal
Hydraulic Tank Capacity 9.5 gal
Workbed Height 31.4"
Weight 4,707 lbs
Floorspace (LxWxH) 100.8" x 107.8" x 75"
