Flexible Mid-Length CNC Tube Laser.
Lasertube systems are our 2D and 3D laser cutting systems for tubes, bars and profiles, from 20 mm to 280 mm in diameter and up to 12000 mm in length.
With the new TubeCutter cutting head equipped on the FLT-7028HT, you will produce high quality parts. With automatic focus and integrated laser parameter management, there is no need for adjustments.
KEY FEATURES:
• Improved clamping balance for variable lengths
• Ideal for mid-size manufacturers
• High-accuracy laser cutting for furniture, equipment
• Applications: Furniture, mechanical parts, steel fabrication
| Laser Power Kw | 6 - 20Kw (custom) | 6 - 20Kw (custom) |
| Max Tube Diameter | 400mm (15") | 400mm (15") |
| Tube Length | 6.5 - 9m (20ft - 30ft) | 6.5 - 9m (20ft - 30ft) |
| Chuck Type | Square/Circle | Square/Circle |
| Number of Chucks | 3 automatic adjustable chucks | 3 automatic adjustable chucks |
| Profiles | Round, square, rectangular, elliptical, C-channel, I-beam, etc. | Round, square, rectangular, elliptical, C-channel, I-beam, etc. |
| Positioning Accuracy | 0.05mm (0.002") | 0.05mm (0.002") |
| Repeatability | 0.05mm (0.002") | 0.05mm (0.002") |
| Automatic Loading/Unloading System | Available | Available |
| 5 Axis Cutting Head | Available | Available |
| Laser Source Type | Raycus/IPG/ max photonics/ JQ | Raycus/IPG/ max photonics/ JQ |
| Safety Enclosure & Interlocks | Yes | Yes |
| CAD/CAM Software Compatibility | STEP, IGES, DXF, TEKLA, etc... | STEP, IGES, DXF, TEKLA, etc... |
High-precision guiding rails
Smart control system
