USED IMO DELAVAL HJ-MV-SF-SAE

Used 11 MW (11,000 KW) IMO DELAVAL, Model HJ-MV-SF-SAE, Steam Turbine Generator. 9 stages.Stage Number 9. Speed 8,936 rpm. Rating 10,695 KW. Steam Pressure 645 PSIG. Generator: Manufacturer Electric Machinery (Dresser), Type Enclosed Water Cooled, Voltage 4,160, Frequency 60 Hz, Rating 12,222 KVA, 11,000 KW, Power Factor 0.9 Speed 1,800 rpm. Gear: Manufacturer Philadelphia Gear, Type Single Reduction Parallel Axis, Model 17HSA, Rating, 14,751 KW / 11,000 KW, Service Factor 1.3, Point Speed 8,936 rpm, Gear Speed 1,800 rpm, Ratio 4.964:1. Built 1988.

Material: Unknown
Capacity: 11000 KW
