USED COGEIM FPP/XD500

Used 5 Square Meter 3V Cogeim Model FPP/XD500 316L Stainless Steel Nutsche Filter. Shell rated 75 psi/FV (5.2 bar/FV) at -4 F to 536 F (-20 C to 280 C). 304 Stainless Steel 1/2 pipe jacket rated 150psi/FV (10.34 bar/FV) at 536 F to -4 F (-20 C to 280 C). Capacity 13,100 liters. Shell dimensions: 8'6.362" x 6'3.354" vertical. Openings: manhole - 23.22", side discharge hatch - 18.50", product inlet -NPS4 and others. With hydraulic driven 40HP heated shaft. Mechanical seal. Serial # 1334, National Board # 301, Built 2000. Estimated weight - 34,254 lbs (15,570 KG).

Material: Stainless Steel
Capacity: 5 Sq Meter
